Battery Thermal Management System (Air-Cooled Condenser)

EVantage_withdescriptor_CMYK

As you design the future of clean technology, Modine is ready to help with proven thermal systems engineered to quickly and seamlessly integrate into your design.

Control Your Battery’s Temperature in All Environments

EVANTAGE™ BTMS AIR-COOLED CONDENSER

Combining state-of-the-art, proprietary Modine heat exchanger technology with tailored smart electronic products, the EVantage BTMS delivers a complete solution, designed to fit any chassis. With the included master thermal controller and Modine-developed firmware, our compact system is proven to deliver maximum cooling at the lowest power draw.

3-Stage Cooling and Heating for Optimized Operation

With multi-stage cooling and heating, the EVantage A-CON BTMS optimizes the temperature range for an entire bank of batteries with a single unit in all types of environments –from hot summer afternoons to icy winter mornings.

Schematic_line artREV4

The smart control system of the A-CON BTMS continuously compares the battery coolant temperature to ambient temperature and automatically selects the most efficient mode of operation while minimizing power draw.

OperationTemp_Chart

Plug and Play for Fast Integration

EVantage systems are designed for fast and easy integration into your chassis. All necessary heat exchangers, smart electric products, wiring and hoses are included, as well as a master controller and tailored firmware to provide complete operation upon delivery.

Our team of Modine application engineers will validate that one of our standard configuration systems meets your needs or customize a design to fit your application.

Excavator,In,Construction,Site,On,Sunset,Sky,Background

Designed for Heavy Duty Operation

Verified to meet the most stringent validation testing, EVantage systems have been proven to withstand heavy vibration environments with Modine-fabricated rugged, anti-corrosive enclosures and flexible, vehicle-grade wiring harnesses and refrigerant hoses.

Avoid Roadside Breakdowns

Each EVantage system is designed with redundancy in critical operations and fail-safe features to minimize field breakdowns. To find and fix issues before they occur, the system offers continuous datalogging of DM1 & DM2 faults and tracks the accumulated runtime on each component, enabling preventative maintenance. When a repair is needed, the included EVantage Maintenance and Diagnostics software makes it easy to find and fix the failure.

Engineer,And,Worker,Planning,For,Construction,Building,And,Renovate,In
SeeThroughTruckComp_REV2

Designed to Fit Any Chassis

From Delivery Vans to Class 8 Trucks to Buses, Modine is ready to design a solution to meet the space constraints of any size chassis, from minor modifications of existing configurations to fully custom systems. Our designs are proven with over 30 programs currently in testing or full-scale production today.

This Product is Buy America Compliant

This product is Buy America Compliant. This product was engineered and tested in Racine, WI. Manufactured in Lawrenceburg, TN, with 70% domestic content, our products are American OEMs’ preferred choice.

MODINE_BUYAMERICACOMPLIANT_RGB
Corporate_RGB

Save Time with Validation Testing by Modine

With a state-of-the-art testing facility in Wisconsin, Modine offers comprehensive validation testing inhouse, from vehicular wind tunnel testing to component-level performance testing. Full vehicle vibration, pressure and thermal life cycle testing can be completed as well. Over the 100 years Modine has been in business, we have developed and perfected tests to verify design and replicate in-field experiences.

Evantage Thermal Systems Features

Icon_Customizable
Customizable – Multiple configurations for different space constraints and cooling capacity
Icon_Reliable

Reliable – Modine patented fail-safe system for maximum system reliability

Icon_Flexible
Flexible – Different mounting options – roof, chassis, body – available
Icon_Convenient

Convenient – Included master thermal controller with Modine-developed firmware and SAEJ1939 CAN communications

Icon_WeatherSafe

Weather Safe – Designed for harsh environments – IP67 ingress protection, corrosion resistant materials, fully sealed wiring harness, rigorous validation testing

Icon_EasyMaintenance

Easy Maintenance – Included Maintenance and Diagnostics Software for system monitoring, diagnostics message data logging and preventative maintenance tracking

SchoolBus
Safely deliver your passengers every day with our cost-effective, high reliability thermal systems
School Bus
CityBus
Avoid roadside breakdowns and ensure dependable operation of your bus with our efficient, high reliability thermal systems
Transit & Coach Bus
AdobeStock_67867627-grey
Ensure a long life for your truck despite harsh environments and heavy vibration use with our robust, proven thermal systems
Truck
DeliveryTruck
Fit the tight space constraints and extended range requirements of your delivery van with our compact thermal systems
Delivery Van

Customer Testimonials

Eric Fisher

The collaboration between Shyft and Modine builds on each company’s strengths. Our expertise in developing and manufacturing custom chassis and work truck bodies through our Shyft Work-Driven Design™ process combined with Modine’s deep experience in EV thermal management for medium-duty trucks means we can help ensure safety and functionality for our commercial electric fleet customers.”

David White

The EVantage BTMS provides dependability for our customers while meeting our environmental and cooling load requirements. We are proud to collaborate with Modine in building the future of innovative and sustainable mobility solutions.

Roger Lackore

Strategic partnerships like the one with Modine help us minimize the environmental impact of our products by accelerating the use of alternative energy in the firefighting industry, and do so with reliable and cost-effective solutions for our customers.

Tim Letts

At Elgin, we designed the hybrid Pelican to deliver outstanding maneuverability and visibility while making a meaningful reduction in emissions without reducing the sweep performance our customers expect. We are committed to using the latest technologies for the street sweeping industry to meet the sustainability goals of our customers. Together with Modine, we are powering a generation of sweepers that pollute less to deliver truly cleaner and greener streets across North America. We are excited for this partnership and the integration of advanced thermal management technology to continue delivering uncompromised performance for heavy-duty cycle sweeping applications.

Contact Us to Learn More.
